Wilwood Aluminum Master Cylinders 261-16797-BK

These Wilwood lightweight aluminum master cylinders provide reliable stopping power for drag race cars, late model stock cars, and off-road vehicles. They utilize standard OEM internal components for dependable performance at an affordable price. They are available with or without large-capacity plastic reservoir and dual outlet bores for responsive performance.Brand: Wilwood Disc Brakes
Manufacturer's Part Number: 261-16797-BK
Part Type: Master Cylinders
Product Line: Wilwood Aluminum Master Cylinders
HP Direct Part Number: WIL-261-16797-BK
UPC: 889545105711
Master Cylinder Usage: Brake
Master Cylinder Bore Size: 1.000 in.
Power Brake Compatible: Yes
Outlet Quantity: 2
Outlet Size 1: 1/2 in.-20
Outlet Size 2: 1/2 in.-20
Master Cylinder Material: Aluminum
Master Cylinder Finish: Black
Bowl Design: Dual
Mounting Hole Quantity: 4 holes
Mounting Flange Center to Center Distance (in.): 3.250
Master Cylinder Stroke: 1.100 in.
Remote Reservoir: No
Reservoir Included: Yes
Reservoir Material: Aluminum
Reservoir Color: Black
Master Cylinder Cap Included: Yes
Pushrod Included: No
Mounting Brackets Included: Yes
Hardware Included: Yes
Remanufactured: No
Quantity: Sold as a kit.
Notes: Uses 4-bolt Mopar 3.25 in. by 1.76 in. mounting pattern. Includes knob-adjustable proportioning valve.
