Description
Nitrous Express is now offering popular intake manifolds that are pre-plumbed with NX nitrous systems. These intakes are brand new and installations have been completed by the expert technicians at NX—so you can simply pull the intake out of the box and install it on your engine. Each component of the nitrous system has been inspected upon installation, and the entire setup has been leak-checked and flow-tested.
This system includes a custom set of bars plumbed into the intake manifold, one NX Lightning Series nitrous solenoid, one NX Lightning Series fuel solenoid, anodized aluminum distribution blocks, and stainless steel fittings—all plumbed inside the manifold! Systems include jetting for 100-400 hp, stainless steel braided nitrous feed lines, a wide open throttle switch, 40 amp relays and relay harnesses, master arming switch, stainless bottle brackets, and a 10 lb. nitrous bottle with the NX Lightning bottle valve.
NX Lightning solenoids feature an improved flow path that allows nitrous / fuel to enter above the seat and exit out the bottom for flow unmatched by any other solenoid on the market. Lightning nitrous solenoids feature an integrated purge port which allows you to connect a purge valve directly to the body of the nitrous solenoid. Purging through the body of the solenoid eliminates the air pocket between the purge valve and the solenoid orifice. Lightning fuel solenoids feature a fuel bypass port which enables you to connect a small return line to the tank. This eliminates trapped air between the fuel pressure regulator and the fuel solenoid, eliminating the lean spike associated with other solenoids. Lightning Series solenoids feature CNC aluminum bodies topped with carbon fiber cans for the ultimate in weight savings. Nitrous Express only uses the highest quality domestic components in its solenoids. Don't be fooled by low price come-ons; the solenoids are the most important component of a nitrous system.
The billet aluminum Lightning bottle valve not only looks great, it's packed with features—including an integrated gauge port, an integrated push port, a large .500 orifice, and a direct flow path.
Brand: Nitrous Express (NX)
Manufacturer's Part Number: INTAKE013
Part Type: Nitrous Oxide Systems
Product Line: Nitrous Express Factory Intakes with Hidden Spray Bars
HP Direct Part Number: NEX-INTAKE013
UPC: 653374975612
Delivery Style: Direct port/Intake manifold
Nitrous System Style: Wet
Nitrous System Intended Fuel Type: Gasoline
Maximum Advertised Horsepower Increase: 400
Activation: Microswitch
Jet Sizes Included (HP): 75, 100, 150, 200, 250, 300, 350, 400
Bottle Included: Yes
Nitrous Bottle Capacity: 10 lbs.
Dual Stage: No
Bottle Material: Aluminum
Bottle Color: White
Bottle Brackets Included: Yes
Bottle Bracket Material: Stainless steel
Quantity: Sold as a kit.
Notes: Designed for LS3 cylinder heads. This system includes a custom set of bars plumbed into the intake manifold, 1 NX Lightning series nitrous solenoid, 1 NX Lightning series fuel solenoid, anodized aluminum distribution blocks, and stainless steel fittings, all plumbed inside the manifold.
This system includes a custom set of bars plumbed into the intake manifold, one NX Lightning Series nitrous solenoid, one NX Lightning Series fuel solenoid, anodized aluminum distribution blocks, and stainless steel fittings—all plumbed inside the manifold! Systems include jetting for 100-400 hp, stainless steel braided nitrous feed lines, a wide open throttle switch, 40 amp relays and relay harnesses, master arming switch, stainless bottle brackets, and a 10 lb. nitrous bottle with the NX Lightning bottle valve.
NX Lightning solenoids feature an improved flow path that allows nitrous / fuel to enter above the seat and exit out the bottom for flow unmatched by any other solenoid on the market. Lightning nitrous solenoids feature an integrated purge port which allows you to connect a purge valve directly to the body of the nitrous solenoid. Purging through the body of the solenoid eliminates the air pocket between the purge valve and the solenoid orifice. Lightning fuel solenoids feature a fuel bypass port which enables you to connect a small return line to the tank. This eliminates trapped air between the fuel pressure regulator and the fuel solenoid, eliminating the lean spike associated with other solenoids. Lightning Series solenoids feature CNC aluminum bodies topped with carbon fiber cans for the ultimate in weight savings. Nitrous Express only uses the highest quality domestic components in its solenoids. Don't be fooled by low price come-ons; the solenoids are the most important component of a nitrous system.
The billet aluminum Lightning bottle valve not only looks great, it's packed with features—including an integrated gauge port, an integrated push port, a large .500 orifice, and a direct flow path.
Brand: Nitrous Express (NX)
Manufacturer's Part Number: INTAKE013
Part Type: Nitrous Oxide Systems
Product Line: Nitrous Express Factory Intakes with Hidden Spray Bars
HP Direct Part Number: NEX-INTAKE013
UPC: 653374975612
Delivery Style: Direct port/Intake manifold
Nitrous System Style: Wet
Nitrous System Intended Fuel Type: Gasoline
Maximum Advertised Horsepower Increase: 400
Activation: Microswitch
Jet Sizes Included (HP): 75, 100, 150, 200, 250, 300, 350, 400
Bottle Included: Yes
Nitrous Bottle Capacity: 10 lbs.
Dual Stage: No
Bottle Material: Aluminum
Bottle Color: White
Bottle Brackets Included: Yes
Bottle Bracket Material: Stainless steel
Quantity: Sold as a kit.
Notes: Designed for LS3 cylinder heads. This system includes a custom set of bars plumbed into the intake manifold, 1 NX Lightning series nitrous solenoid, 1 NX Lightning series fuel solenoid, anodized aluminum distribution blocks, and stainless steel fittings, all plumbed inside the manifold.
