Description
MSD Blaster SS coils fire up your ignition with 40,000 V of power! When used with an MSD 6 Series ignition, these MSD Blaster SS coils delivered 300 milliamps of spark. The coils feature efficient E-core windings, brass terminals, and a durable Rynite housing.Brand: MSD Ignition
Manufacturer's Part Number: 8207
Part Type: Ignition Coils
Product Line: MSD Blaster SS Coils
HP Direct Part Number: MSD-8207
UPC: 085132082070
Coil Style: Remote mount
Primary Resistance: 0.355 ohms
Coil Internal Construction: Epoxy
Coil Wire Attachment: Male/HEI
Coil Color: Red
Maximum Voltage: 40,000 V
Turns Ratio: 70:1
Secondary Resistance: 4.40K ohms
Inductance: 6.90 mH
Peak Current: 300 mA
Spark Duration: 220 uS
Mounting Bracket Included: No
Coil Wire Included: No
Ballast Resistor Included: No
Coil Shape: Square
Height (in.): 2.650 in.
Length (in.): 3.500 in.
Width (in.): 2.230 in.
Quantity: Sold individually.
CARB EO Number(s): D-40-37
Emissions: California EO Approved
Manufacturer's Part Number: 8207
Part Type: Ignition Coils
Product Line: MSD Blaster SS Coils
HP Direct Part Number: MSD-8207
UPC: 085132082070
Coil Style: Remote mount
Primary Resistance: 0.355 ohms
Coil Internal Construction: Epoxy
Coil Wire Attachment: Male/HEI
Coil Color: Red
Maximum Voltage: 40,000 V
Turns Ratio: 70:1
Secondary Resistance: 4.40K ohms
Inductance: 6.90 mH
Peak Current: 300 mA
Spark Duration: 220 uS
Mounting Bracket Included: No
Coil Wire Included: No
Ballast Resistor Included: No
Coil Shape: Square
Height (in.): 2.650 in.
Length (in.): 3.500 in.
Width (in.): 2.230 in.
Quantity: Sold individually.
CARB EO Number(s): D-40-37
Emissions: California EO Approved
