Injector Dynamics F750 Fuel Filters F750

Injector Dynamics F750 fuel filters are the first performance filter designed to meet strict OE requirements, namely Bosch's specification for electronic fuel injectors. They're the result of substantial research invested in improving the service life of your injectors. The modular bracket design allows for numerous mounting options, from the standard 90 degree, straight, and reverse 90 degree—to roll bar tube mounting and everything in-between.

At a flow rate of 750 liters per hour, the ID 750 filter element will hold five grams of contaminant—the equivalent of approximately one teaspoon—before requiring replacement. Their spin-on filter housing features a safety latch to ensure that the housing cannot spin off, should it loosen. It is easily released with one finger and emits an audible click during assembly.
Brand: Injector Dynamics
Manufacturer's Part Number: F750
Part Type: Fuel Filters
Product Line: Injector Dynamics F750 Fuel Filters
HP Direct Part Number: IJD-F750
Fuel Filter Style: Canister
Inlet Quantity: 1
Fuel Filter Inlet Size: -8 AN O-ring
Inlet Attachment: Female threads
Outlet Quantity: 1
Fuel Filter Outlet Size: -8 AN O-ring
Outlet Attachment: Female threads
Filter Element Included: Yes
Smallest Particle Filtered: 5 microns
Filter Housing Material: Aluminum
Filter Housing Color: Gray
Mounting Bracket Included: Yes
Fittings Included: No
Clamps Included: No
Maximum Fuel Pressure (psi): 145
Quantity: Sold individually.
