Edelbrock Victor EFI 4-Barrel Throttle Bodies 4150

Edelbrock Victor EFI 4-barrel throttle bodies are the perfect high-quality, satin finished complement for fuel injection systems based on Victor EFI intake manifolds. They also make affordably priced replacements for similar throttle bodies. These units include four 1.75 in. throttle bores for a 1,000 cfm flow rating. The base flange will fit most of the Edelbrock Victor and Pro-Flo 4-style manifolds (or other similar manifolds with comparable square-bore carburetor flange and standard bolt spacing). These Edelbrock-designed throttle bodies are diecast and fully machined with high-quality components. Get your thrill on running wide-open with Edelbrock Victor EFI 4-barrel throttle bodies!

Features, notes, and specs:

* Will accept standard air cleaners with 5 1/8 in. flange
* Assembly includes Delphi/GM 4-pin stepper-style idle air control (IAC) motor with GM-style 3-pin throttle position sensor (TPS) and 1-bar GM MAP sensor
* Multiple vacuum take-offs (front 3/8 and 1/4; rear 3/8, 1/4, and 3/16—plus another 3/16 on the passenger side)
* MAP sensor mounting location incorporated on housing
* Precision throttle control provided by progressive linkage with provisions for 700R4-style throttle valve cable
* 2.53 in. measurement from base flange to air cleaner flange


Brand: Edelbrock
Manufacturer's Part Number: 4150
Part Type: Throttle Bodies
Product Line: Edelbrock Victor EFI 4-Barrel Throttle Bodies
HP Direct Part Number: EDL-4150
UPC: 085347041503
Throttle Body Style: Multi-port injection, MPI
Throttle Body Actuation: Cable
Venturi Quantity: 4
Airflow Rate (cfm): 1,000 cfm
TPS Sensor Included: Yes
IAC Motor Included: Yes
Gaskets Included: Yes
Hardware Included: Yes
Injectors Included: No
Throttle Body Material: Cast aluminum
Throttle Body Color: Natural
Remanufactured: No
Quantity: Sold individually.
Notes: Designed with 1.75 in. throttle bores and fits square bore carburetor flange intake manifolds only.
