Edelbrock Twin-Force Stage 3 Turbo Systems 158333

Offering a 200 hp increase at the tires over stock, Edelbrock Twin-Force State 3 Turbo Systems will unleash the max potential of your truck. Edelbrock's engineers collaborated with Garrett on the design of all new turbos for the 3.5L EcoBoost trucks. These new direct bolt-in turbos incorporate the latest in turbocharger technology, offering a 54 percent increase in airflow over the factory turbos. A 60mm billet compressor wheel produces great improvements in compressor efficiency and flow. The 50mm Inconnel turbine wheel and larger .45 A/R stainless steel turbine housing result in a 52 percent increase in turbine flow. The 2.75 in. compressor inlets are 38 percent larger than the factory turbos, complementing Edelbrock's high-flow turbo inlet piping.

The new turbochargers—combined with Edelbrock's larger intercooler, air inlet tubes, and high-flow air filter—offer huge increases in power potential for this application. To complement the improvements in airflow, the Stage 3 kits include an electronic booster for the fuel pump, enhancing fuel delivery and unlocking even more power potential. A flashing device (tuner) is included for flashing the Edelbrock Stage 3 calibration into the trucks PCM. The included calibration is specifically engineered for the components included in these kits—and takes advantage of this increased power potential, while keeping this upgrade to your truck EPA legal.

Product notes:

* New turbos with the latest turbocharger technology
* Bolt-in installation with no fabrication required
* EPA legal calibration and tuner (requires a PC)
* OEM quality fit and finish
* 200 hp gain at the wheels over stock
Brand: Edelbrock
Manufacturer's Part Number: 158333
Part Type: Turbocharger Kits
Product Line: Edelbrock Twin-Force Stage 3 Turbo Systems
HP Direct Part Number: EDL-158333
UPC: 085347896011
Turbocharger Style: Stock
Compressor Housing Material: Aluminum
Compressor Housing Color: Natural
Turbine Housing Material: Cast iron
Turbine Housing Finish: Natural
Compressor Wheel Construction: Inconel
Turbocharger Bearing Style: Journal bearing
Turbocharger Quantity: Dual
Exhaust Manifold Included: No
Intercooler Included: Yes
Wastegate Actuator Included: Yes
Wastegate Location: External
Turbocharger Downpipe Included: No
Intercooler Piping Color: Black
Intercooler Pipe Color: Black
Filter Included: Yes
Fuel Injectors Included: No
Computer Chip/Programmer Included: Yes
Gaskets Included: Yes
Hardware Included: Yes
Remanufactured: No
Quantity: Sold as a kit.
Notes: Includes electronic booster, Stage 3 calibration, and tuner.
CARB EO Number(s): D-215-127
Emissions: California EO Approved
