Edelbrock Pro-Port Raw Cylinder Heads 618269

Edelbrock Pro-Port raw cylinder heads are un-ported versions of the Edelbrock race-winning Victor Series CNC heads for the professional cylinder head porter and engine builder. Pro-Port raw cylinder heads are cast with extra-thick walls to allow for custom CNC porting. They are the only heads designed specifically to accommodate almost any CNC port shape, size or location. Some Edelbrock Pro-Port raw heads feature their special Hot Isostatic Pressing or HIP Process.Brand: Edelbrock
Manufacturer's Part Number: 618269
Part Type: Cylinder Heads
Product Line: Edelbrock Pro-Port Raw Cylinder Heads
HP Direct Part Number: EDL-618269
UPC: 085347996407
Cylinder Head Style: Bare
Cylinder Head Material: Cast aluminum
CNC-Machined Combustion Chamber: No
CNC-Machined Intake Runner: No
CNC-Machined Exhaust Runner: No
Spark Plug Style: Angle
Intake Valves Included: No
Exhaust Valves Included: No
Valve Springs Included: No
Damper Spring Included: No
Retainers Included: No
Locks Included: No
Valve Stem Seals Included: No
Rocker Arm Studs Included: No
Rocker Arms Included: No
Rocker Arm Nuts Included: No
Guideplates Included: No
Valve Cover Mounting Style: Perimeter bolt
Accessory Bolt Holes Drilled: Yes
Valve Guides Included: Yes
Valve Guide Material: Manganese bronze
Valve Seats Machined: No
Valve Seat Material: Ductile iron
Cylinder Head Color: Natural
Steam Holes Drilled: No
Machined for O-Ring: No
Heat Crossover: No
Remanufactured: No
Quantity: Sold individually.
Notes: Pro-Port version features unfinished combustion chambers and will require professional porter to complete.
