Edelbrock E-Street Cylinder Heads 77618

Are you looking for a set of entry-level street performance heads for your modern street rod, muscle car, or truck? Edelbrock E-Street cylinder heads are just the ticket. These heads feature A356 aluminum castings that are heat-treated to T-6 specs for superior casting strength and quality. Their modern combustion chamber design helps to improve the combustion process and their larger-than-stock intake and exhaust ports help to move more air through your engine. These features improve an engine's efficiency, resulting in more horsepower and torque and improved mileage potential. All Edelbrock E-Street cylinder heads are assembled with manganese bronze valve guides, powder metal interlocking valve seats, and stainless steel one-piece valves with hardened valve tips. Edelbrock E-Street cylinder heads are ideal for entry level street performance engines.Brand: Edelbrock
Manufacturer's Part Number: 77618
Part Type: Cylinder Heads
Product Line: Edelbrock E-Street Cylinder Heads
HP Direct Part Number: EDL-77618
UPC: 085347776184
Combustion Chamber Volume (cc): 69
Intake Runner Volume (cc): 260cc
Cylinder Head Style: Assembled
Cylinder Head Material: Cast aluminum
Camshaft Style: Hydraulic roller
Intake Port Shape: Rectangular
Intake Valve Diameter (in.): 2.165 in.
CNC-Machined Combustion Chamber: No
CNC-Machined Intake Runner: No
CNC-Machined Exhaust Runner: No
Combustion Chamber Style: Heart
Intake Port Location: Standard
Exhaust Port Shape: D-port
Exhaust Port Location: Standard
Spark Plug Style: Angle
Intake Valves Included: Yes
Exhaust Valves Included: Yes
Exhaust Valve Diameter (in.): 1.590 in.
Valve Springs Included: Yes
Maximum Valve Lift (in.): 0.660 in.
Outside Diameter of Outer Spring (in.): 1.282 in./1.077 in.
Damper Spring Included: No
Number of Springs Per Valve: Dual
Retainers Included: Yes
Retainer Material: Steel
Locks Included: Yes
Lock Style: 7 degree
Valve Stem Seals Included: No
Valve Stem Seal Style: Umbrella
Rocker Arm Studs Included: No
Rocker Arms Included: No
Rocker Arm Nuts Included: No
Guideplates Included: No
Valve Cover Mounting Style: Centerbolt
Accessory Bolt Holes Drilled: Yes
Intake Valve Angle: 15
Exhaust Valve Angle: 15
Valve Guides Included: Yes
Valve Guide Material: Manganese bronze
Valve Seats Machined: Yes
Valve Seat Machine Style: 3-angle
Valve Seat Material: Ductile iron
Cylinder Head Color: Natural
Finish: Natural
Steam Holes Drilled: No
Machined for O-Ring: No
Heat Crossover: No
Remanufactured: No
Quantity: Sold as a pair.
Notes: A unique dual spark plug pocket design allows you to use the factory-style tapered-seat spark plugs or gasket seat spark plugs available in wider heat ranges for maximum tuning ability.
CARB EO Number(s): NO
Emissions: California EO Approved
