Description
Edelbrock E-CNC 215 cylinder heads are ideal for street cruisers or dual-purpose rides needing the capability to build around 450 hp. They feature fully CNC-machined exhaust ports, intake ports, and combustion chambers for increased airflow. These heads are available completed or bare and ready for your new parts. Produce the power you need for your 1997 and later LS1/LS2 with Edelbrock E-CNC 215 cylinder heads.Brand: Edelbrock
Manufacturer's Part Number: 79949
Part Type: Cylinder Heads
Product Line: Edelbrock E-CNC 215 Cylinder Heads
HP Direct Part Number: EDL-79949
UPC: 085347799497
Combustion Chamber Volume (cc): 65
Intake Runner Volume (cc): 212cc
Exhaust Runner Volume (cc): 76cc
Cylinder Head Style: Assembled
Cylinder Head Material: Cast aluminum
Camshaft Style: Hydraulic roller
Intake Port Shape: Cathedral
Intake Valve Diameter (in.): 2.020 in.
CNC-Machined Combustion Chamber: Yes
CNC-Machined Intake Runner: Yes
CNC-Machined Exhaust Runner: Yes
Combustion Chamber Style: Heart
Intake Port Location: Standard
Exhaust Port Shape: Round
Exhaust Port Location: Standard
Spark Plug Style: Angle
Intake Valves Included: Yes
Exhaust Valves Included: Yes
Exhaust Valve Diameter (in.): 1.570 in.
Valve Springs Included: Yes
Maximum Valve Lift (in.): 0.600 in.
Outside Diameter of Outer Spring (in.): 1.550 in./1.300 in.
Damper Spring Included: No
Retainers Included: Yes
Retainer Material: Steel
Locks Included: Yes
Valve Stem Seals Included: Yes
Valve Stem Seal Style: Positive stop
Rocker Arm Studs Included: No
Rocker Arms Included: No
Rocker Arm Nuts Included: No
Guideplates Included: No
Valve Cover Mounting Style: Perimeter bolt
Accessory Bolt Holes Drilled: Yes
Intake Valve Angle: 15
Valve Guides Included: Yes
Valve Guide Material: Manganese steel
Valve Seats Machined: Yes
Valve Seat Machine Style: 3-angle
Valve Seat Material: Ductile iron
Cylinder Head Color: Natural
Steam Holes Drilled: No
Oiling Style: Through pushrod
Machined for O-Ring: No
Heat Crossover: No
Remanufactured: No
Quantity: Sold individually.
CARB EO Number(s): D-215-70
Emissions: California EO Approved
Manufacturer's Part Number: 79949
Part Type: Cylinder Heads
Product Line: Edelbrock E-CNC 215 Cylinder Heads
HP Direct Part Number: EDL-79949
UPC: 085347799497
Combustion Chamber Volume (cc): 65
Intake Runner Volume (cc): 212cc
Exhaust Runner Volume (cc): 76cc
Cylinder Head Style: Assembled
Cylinder Head Material: Cast aluminum
Camshaft Style: Hydraulic roller
Intake Port Shape: Cathedral
Intake Valve Diameter (in.): 2.020 in.
CNC-Machined Combustion Chamber: Yes
CNC-Machined Intake Runner: Yes
CNC-Machined Exhaust Runner: Yes
Combustion Chamber Style: Heart
Intake Port Location: Standard
Exhaust Port Shape: Round
Exhaust Port Location: Standard
Spark Plug Style: Angle
Intake Valves Included: Yes
Exhaust Valves Included: Yes
Exhaust Valve Diameter (in.): 1.570 in.
Valve Springs Included: Yes
Maximum Valve Lift (in.): 0.600 in.
Outside Diameter of Outer Spring (in.): 1.550 in./1.300 in.
Damper Spring Included: No
Retainers Included: Yes
Retainer Material: Steel
Locks Included: Yes
Valve Stem Seals Included: Yes
Valve Stem Seal Style: Positive stop
Rocker Arm Studs Included: No
Rocker Arms Included: No
Rocker Arm Nuts Included: No
Guideplates Included: No
Valve Cover Mounting Style: Perimeter bolt
Accessory Bolt Holes Drilled: Yes
Intake Valve Angle: 15
Valve Guides Included: Yes
Valve Guide Material: Manganese steel
Valve Seats Machined: Yes
Valve Seat Machine Style: 3-angle
Valve Seat Material: Ductile iron
Cylinder Head Color: Natural
Steam Holes Drilled: No
Oiling Style: Through pushrod
Machined for O-Ring: No
Heat Crossover: No
Remanufactured: No
Quantity: Sold individually.
CARB EO Number(s): D-215-70
Emissions: California EO Approved
