Edelbrock E-CNC 185 Cylinder Heads 79895

Edelbrock E-CNC 185 cylinder heads feature fully CNC-machined intake ports, combustion chambers, and exhaust ports for improved performance. Their all-new design delivers optimal airflow for maximum horsepower and torque in high performance street vehicles and small engine racing applications. The heads maintain the stock 23 degree valve angle and the intake flange is drilled to accept 1986 and earlier intake manifold designs. The CNC-machined ports give you a 64cc combustion chamber, a 185cc intake runner, and a 75cc exhaust port.Brand: Edelbrock
Manufacturer's Part Number: 79895
Part Type: Cylinder Heads
Product Line: Edelbrock E-CNC 185 Cylinder Heads
HP Direct Part Number: EDL-79895
UPC: 085347798957
Combustion Chamber Volume (cc): 64
Intake Runner Volume (cc): 185cc
Exhaust Runner Volume (cc): 75cc
Cylinder Head Style: Assembled
Cylinder Head Material: Cast aluminum
Camshaft Style: Hydraulic roller
Intake Port Shape: Rectangular
Intake Valve Diameter (in.): 2.020 in.
CNC-Machined Combustion Chamber: Yes
CNC-Machined Intake Runner: Yes
CNC-Machined Exhaust Runner: Yes
Combustion Chamber Style: Kidney
Intake Port Location: Standard
Exhaust Port Shape: Round
Exhaust Port Location: Standard
Spark Plug Style: Straight
Intake Valves Included: Yes
Exhaust Valves Included: Yes
Exhaust Valve Diameter (in.): 1.600 in.
Valve Springs Included: Yes
Maximum Valve Lift (in.): 0.575 in.
Outside Diameter of Outer Spring (in.): 1.460 in.
Damper Spring Included: Yes
Number of Springs Per Valve: Dual
Retainers Included: Yes
Retainer Material: Steel
Locks Included: Yes
Lock Style: 7 degree
Valve Stem Seals Included: Yes
Valve Stem Seal Style: Positive stop
Rocker Arm Studs Included: Yes
Rocker Arm Nut Thread Size: 3/8 in.-24
Rocker Arms Included: No
Rocker Arm Nuts Included: No
Guideplates Included: Yes
Guideplate Pushrod Size: 5/16 in.
Valve Cover Mounting Style: Perimeter bolt
Accessory Bolt Holes Drilled: Yes
Intake Valve Angle: 23
Valve Guides Included: Yes
Valve Guide Material: Manganese bronze
Valve Seats Machined: Yes
Valve Seat Machine Style: 3-angle
Valve Seat Material: Powdered metal
Cylinder Head Color: Natural
Steam Holes Drilled: No
Oiling Style: Through pushrod
Machined for O-Ring: No
Heat Crossover: No
Remanufactured: No
Quantity: Sold individually.
