Description
Intended for high output, large cubic inch big block Chevy racing engines with 4.84 in. bore spacing, these Edelbrock Big Victor Spread-Port CNC heads are an improvement over existing designs. The casting is made from A-356 aluminum and is Hot Isostatic Pressing processed (HIP) for superior strength and durability, dimensional stability, and exceptional finish quality. These heads feature CNC-ported spread intake ports and a raised exhaust runner design for improved flow efficiency. The chambers are also fully CNC-ported and Edelbrock includes extra material in the deck to allow for fine tuning of the combustion chamber design if desired.Brand: Edelbrock
Manufacturer's Part Number: 618270
Part Type: Cylinder Heads
Product Line: Edelbrock Big Victor Spread-Port Bare CNC Cylinder Heads
HP Direct Part Number: EDL-618270
UPC: 085347897476
Combustion Chamber Volume (cc): 82
Intake Runner Volume (cc): 498cc
Cylinder Head Style: Bare
Cylinder Head Material: Cast aluminum
Intake Port Shape: Oval
Intake Valve Diameter (in.): 2.500 in.
CNC-Machined Combustion Chamber: Yes
CNC-Machined Intake Runner: Yes
CNC-Machined Exhaust Runner: Yes
Intake Port Location: Raised
Exhaust Port Shape: Round
Exhaust Port Location: Raised
Spark Plug Style: Angle
Intake Valves Included: No
Exhaust Valves Included: No
Exhaust Valve Diameter (in.): 1.800 in.
Valve Springs Included: No
Damper Spring Included: No
Retainers Included: No
Locks Included: No
Valve Stem Seals Included: No
Rocker Arm Studs Included: No
Rocker Arms Included: No
Rocker Arm Nuts Included: No
Guideplates Included: No
Valve Cover Mounting Style: Perimeter bolt
Accessory Bolt Holes Drilled: Yes
Intake Valve Angle: 12
Exhaust Valve Angle: 12
Valve Guides Included: Yes
Valve Guide Material: Manganese bronze
Valve Seats Machined: No
Valve Seat Material: Copper
Cylinder Head Color: Natural
Finish: Natural
Steam Holes Drilled: No
Oiling Style: Through pushrod
Machined for O-Ring: No
Heat Crossover: No
Remanufactured: No
Quantity: Sold individually.
Notes: Specifically designed for maximum competition naturally aspirated, nitrous injected, and boosted applications. Head has been through hot isostatic pressing (HIP) for a more stable and dense grain structure.
Manufacturer's Part Number: 618270
Part Type: Cylinder Heads
Product Line: Edelbrock Big Victor Spread-Port Bare CNC Cylinder Heads
HP Direct Part Number: EDL-618270
UPC: 085347897476
Combustion Chamber Volume (cc): 82
Intake Runner Volume (cc): 498cc
Cylinder Head Style: Bare
Cylinder Head Material: Cast aluminum
Intake Port Shape: Oval
Intake Valve Diameter (in.): 2.500 in.
CNC-Machined Combustion Chamber: Yes
CNC-Machined Intake Runner: Yes
CNC-Machined Exhaust Runner: Yes
Intake Port Location: Raised
Exhaust Port Shape: Round
Exhaust Port Location: Raised
Spark Plug Style: Angle
Intake Valves Included: No
Exhaust Valves Included: No
Exhaust Valve Diameter (in.): 1.800 in.
Valve Springs Included: No
Damper Spring Included: No
Retainers Included: No
Locks Included: No
Valve Stem Seals Included: No
Rocker Arm Studs Included: No
Rocker Arms Included: No
Rocker Arm Nuts Included: No
Guideplates Included: No
Valve Cover Mounting Style: Perimeter bolt
Accessory Bolt Holes Drilled: Yes
Intake Valve Angle: 12
Exhaust Valve Angle: 12
Valve Guides Included: Yes
Valve Guide Material: Manganese bronze
Valve Seats Machined: No
Valve Seat Material: Copper
Cylinder Head Color: Natural
Finish: Natural
Steam Holes Drilled: No
Oiling Style: Through pushrod
Machined for O-Ring: No
Heat Crossover: No
Remanufactured: No
Quantity: Sold individually.
Notes: Specifically designed for maximum competition naturally aspirated, nitrous injected, and boosted applications. Head has been through hot isostatic pressing (HIP) for a more stable and dense grain structure.
