CP Pistons Toyota Piston and Ring Kits SC8473

CP Pistons Toyota piston and ring kits aren't just any piston and ring kits. No, they're a blending of creativity, experience, and proven technology, making them the best pistons for your application. These high-strength forged aluminum pistons are CNC-machined and balanced to within +/- 1 gram, ensuring that all of your pistons are created equal. Toyota pistons have custom skirt cam and barrel designs to optimize maximum performance for your application. CP pistons have full radiused dome designs with deep valve reliefs, making them compatible with oversized valves and higher lift cams. With their high performance rings and accumulator grooves, lightweight pins, and double pin oilers, these are not your ordinary pistons--they're engineered for ultimate power in your sport compact.Brand: CP-Carrillo
Manufacturer's Part Number: SC8473
Part Type: Pistons
Product Line: CP Pistons Toyota Piston and Ring Kits
HP Direct Part Number: CNN-SC8473
Piston Rings Included: Yes
Bore (in.): 3.425 in.
Bore (mm): 87.000mm
Stroke: 86.00mm
Engine Stroke Type: Stock
Actual Engine Displacement: 3.1L/189
Rod Length: 142.000mm
Piston Style: Dome, with four valve reliefs
Piston Material: Forged aluminum
Compression Height (in.): 1.338 in.
Dome Height (in.): 0.045 in.
Piston Head Volume (cc): +2.80cc
Wrist Pin Style: Press-fit or floating
Wrist Pin Retainers Included: Yes
Wrist Pin Included: Yes
Pin Diameter (in.): 0.866 in.
Piston Ring Thickness: 1.20mm x 1.20mm x 2.00mm
File Fit: No
Gapless: No
Top Ring Thickness: 1.2mm
Top Ring Material: Steel
Top Ring Facing Material: PVD
Second Ring Thickness: 1.2mm
Second Ring Material: Cast iron
Second Ring Facing Material: Cast iron
Oil Ring Thickness: 2.0mm
Oil Ring Material: Carbon steel
Oil Ring Facing Material: Nitride
Oil Ring Tension: Low
Remanufactured: No
Quantity: Sold individually.
Notes: Can be used in turbo, supercharger, and nitrous applications.
