CP Pistons Honda R-Series Piston and Ring Kits SC7023-4

CP-Carrillo offers piston and ring kits for a variety of sport compact vehicles, including many Honda R-Series engine applications from 2006 and up. Forged from aluminum for additional strength, durability, and weight reduction, CP pistons represent the highest quality and are engineered for maximum power. They are available in different bore sizes and piston head volume, individually or in a set of four.

Standard features include:

* Deep valve reliefs accommodate high lift camshafts
* Larger valve reliefs for +1mm valve sizes
* Custom skirt cam and barrel design
* Accumulator grooves
* High performance rings
* Fully CNC-machined and balanced to +/- gram; wrist pins included
* Double pin oilers force fed from oil ring groove
* Pin lock grooves for easy lock removal
* Pin fitting included
Brand: CP-Carrillo
Manufacturer's Part Number: SC7023-4
Part Type: Pistons
Product Line: CP Pistons Honda R-Series Piston and Ring Kits
HP Direct Part Number: CNN-SC7023-4
Piston Rings Included: Yes
Bore (in.): 3.189 in.
Bore (mm): 81.000mm
Stroke: 87.30mm
Engine Stroke Type: Stock
Rod Length: 157.500mm
Piston Style: Dish, with four valve reliefs
Piston Material: Forged aluminum
Compression Height (in.): 1.135 in.
Piston Head Volume (cc): +15.50cc
Wrist Pin Style: Press-fit or floating
Wrist Pin Retainers Included: Yes
Wrist Pin Included: Yes
Pin Diameter (in.): 0.787 in.
Piston Ring Thickness: 1.00mm x 1.20mm x 2.80mm
File Fit: No
Gapless: No
Top Ring Thickness: 1.0mm
Top Ring Material: Steel
Top Ring Facing Material: Gas nitrided
Second Ring Thickness: 1.2mm
Second Ring Material: Cast iron
Second Ring Facing Material: Ductile napier
Oil Ring Thickness: 2.8mm
Oil Ring Tension: Low
Remanufactured: No
Quantity: Sold as a set of 4.
