Description
Designed for hot street/strip cars, COMP Cams Magnum series cams require a higher compression ratio, rear-end gear ratio, and stall torque converter than stock. With a very aggressive profile, these Magnum hydraulic camshafts provide maximum top-end performance for your high performance car.Brand: COMP Cams
Manufacturer's Part Number: 10-210-4
Part Type: Camshafts
Product Line: COMP Cams Magnum Hydraulic Camshafts
HP Direct Part Number: CCA-10-210-4
UPC: 036584610014
Cam Style: Hydraulic flat tappet
Camshaft Use: Street/Strip
Camshaft Manufacturers Description: Street/strip cam for 360 and up. Use 10:1 compression with 3000+ converter and low gears. Very rough idle.
Basic Operating RPM Range: 2,500-6,500
Intake Duration at 050 inch Lift: 244
Exhaust Duration at 050 inch Lift: 244
Duration at 050 inch Lift: 244 int./244 exh.
Advertised Intake Duration: 292
Advertised Exhaust Duration: 292
Advertised Duration: 292 int./292 exh.
Intake Valve Lift with Factory Rocker Arm Ratio: 0.518 in.
Exhaust Valve Lift with Factory Rocker Arm Ratio: 0.518 in.
Valve Lift with Factory Rocker Arm Ratio: 0.518 int./0.518 exh.
Lobe Separation (degrees): 110
Remanufactured: No
Computer-Controlled Compatible: No
Grind Number: A 292H-10
Valve Springs Required: Yes
Quantity: Sold individually.
Manufacturer's Part Number: 10-210-4
Part Type: Camshafts
Product Line: COMP Cams Magnum Hydraulic Camshafts
HP Direct Part Number: CCA-10-210-4
UPC: 036584610014
Cam Style: Hydraulic flat tappet
Camshaft Use: Street/Strip
Camshaft Manufacturers Description: Street/strip cam for 360 and up. Use 10:1 compression with 3000+ converter and low gears. Very rough idle.
Basic Operating RPM Range: 2,500-6,500
Intake Duration at 050 inch Lift: 244
Exhaust Duration at 050 inch Lift: 244
Duration at 050 inch Lift: 244 int./244 exh.
Advertised Intake Duration: 292
Advertised Exhaust Duration: 292
Advertised Duration: 292 int./292 exh.
Intake Valve Lift with Factory Rocker Arm Ratio: 0.518 in.
Exhaust Valve Lift with Factory Rocker Arm Ratio: 0.518 in.
Valve Lift with Factory Rocker Arm Ratio: 0.518 int./0.518 exh.
Lobe Separation (degrees): 110
Remanufactured: No
Computer-Controlled Compatible: No
Grind Number: A 292H-10
Valve Springs Required: Yes
Quantity: Sold individually.
