Description
ACT Heavy-Duty Performance clutch discs are available in solid or sprung hub styles. These kits feature ACT's most popular heavy-duty pressure plates, which use exclusive diaphragm design to increase clamp load, reduce deflection, and maximize clutch life. All diaphragms endure a 4-stage heat-treating process for unparalleled performance. Each pressure plate has precision cover stampings to provide rigidity and consistency.
Additional details:
* Light to moderate pedal effort, aggressive engagement, OE to mild gear rattle
* Moderate friction life, extended by ACT's exclusive diaphragm design
* Carefully engineered, precisely assembled, accurately balanced
* Uses select ceramic friction materials for high heat tolerance and maximum performance
* Recommended for high horsepower street or race use
* 100 percent clamp load tested and dynamically computer balanced for smooth high RPM reliability
Select from these two options and features:
* ACT's 6-pad, SPRING-CENTERED race discs feature a spring-center to properly damp torsional vibrations and resist failure under harsh conditions. ACT spring retainers utilize wraparound spring windows and thicker retainer stampings to provide spring support, reduce stress concentrations, and increase strength and reliability. With the 6-pad, spring-centered race disc, engagement is harsher, but shifting is faster. The 6-pad, spring-centered disc is recommended for larger clutch sizes to absorb more heat.
* ACT performance street RIGID-HUB discs feature premium organic materials with high copper content for better heat transfer and steel-backed lining for greater burst strength and durability. The chromoly hub is heat-treated for strength and durability. Rivet design and materials are carefully selected for maximum strength. These discs are the minimum weight street disc for faster shifts. ACT's street rigid-hub discs provide race-proven performance with street manageability.
Brand: Advanced Clutch Technology
Manufacturer's Part Number: BM16-HDSS
Part Type: Clutch Discs
Product Line: ACT Heavy-Duty Performance Clutch Discs
HP Direct Part Number: ACL-BM16-HDSS
UPC: 842385024901
Clutch Usage: Performance
Input Spline Quantity: 22
Input Shaft Diameter: 1.125 in.
Disc Diameter (in.): 9.400 in.
Disc Diameter (mm): 240mm
Disc Material: Organic
Disc Style: Full face
Hub Style: Sprung
Quantity: Sold individually.
Notes: Must be used with ACT flywheel. Pressure plate bolts included. Alignment tool included.
Additional details:
* Light to moderate pedal effort, aggressive engagement, OE to mild gear rattle
* Moderate friction life, extended by ACT's exclusive diaphragm design
* Carefully engineered, precisely assembled, accurately balanced
* Uses select ceramic friction materials for high heat tolerance and maximum performance
* Recommended for high horsepower street or race use
* 100 percent clamp load tested and dynamically computer balanced for smooth high RPM reliability
Select from these two options and features:
* ACT's 6-pad, SPRING-CENTERED race discs feature a spring-center to properly damp torsional vibrations and resist failure under harsh conditions. ACT spring retainers utilize wraparound spring windows and thicker retainer stampings to provide spring support, reduce stress concentrations, and increase strength and reliability. With the 6-pad, spring-centered race disc, engagement is harsher, but shifting is faster. The 6-pad, spring-centered disc is recommended for larger clutch sizes to absorb more heat.
* ACT performance street RIGID-HUB discs feature premium organic materials with high copper content for better heat transfer and steel-backed lining for greater burst strength and durability. The chromoly hub is heat-treated for strength and durability. Rivet design and materials are carefully selected for maximum strength. These discs are the minimum weight street disc for faster shifts. ACT's street rigid-hub discs provide race-proven performance with street manageability.
Brand: Advanced Clutch Technology
Manufacturer's Part Number: BM16-HDSS
Part Type: Clutch Discs
Product Line: ACT Heavy-Duty Performance Clutch Discs
HP Direct Part Number: ACL-BM16-HDSS
UPC: 842385024901
Clutch Usage: Performance
Input Spline Quantity: 22
Input Shaft Diameter: 1.125 in.
Disc Diameter (in.): 9.400 in.
Disc Diameter (mm): 240mm
Disc Material: Organic
Disc Style: Full face
Hub Style: Sprung
Quantity: Sold individually.
Notes: Must be used with ACT flywheel. Pressure plate bolts included. Alignment tool included.
